149 / 150 / 151

Dual Body Pin Headers, 2.54mm Pitch, 1/2/3 Rows

Go to configuration
Note

Technical Data

Insulator Thermoplastic, rated UL94 V-0
Contact Material 0.635mm square pin, copper alloy
Contact Surface Acc. to options (see below), over Ni
Contact Resistance < 20 mΩ
Insulation Resistance > 1000 MΩ
Test Voltage 1 kV DC
Voltage Rating 250 V AC
Current Rating 3 A
Temperature Range -55 °C ... +125 °C
Processing Wave or reflow soldering

Downloads

Data Sheet download

Passende Buchsenleisten:
Compatible Female Headers:
153 154 340 348 624 etc.
Weitere siehe Kapitel B
Please see ch. B for more

Configure your product

W+P PRODUCTS Zeichnung

PCB Layouts und Detailzeichnungen s. tech. Informationen / Seite A12
Please note tech. information / page A12 for PCB layouts and detailed drawings.

Select the desired configuration:

Series
Please select 1 option
Electro-strictioned contacts
149 Single row
150 Double row
151 Triple row
Dimensions
Please select 1 option
16 A=17,70 B=5,70 C=3,30 D=8,70mm
17 A=19,80 B=5,70 C=3,30 D=10,80mm
18 A=21,60 B=5,70 C=3,30 D=12,60mm
19 A=22,80 B=5,70 C=3,30 D=13,80mm
20 A=24,90 B=5,70 C=3,30 D=15,90mm
21 A=26,70 B=5,70 C=3,30 D=17,70mm
22 A=29,00 B=5,70 C=3,30 D=20,00mm
23 A=30,80 B=5,70 C=3,30 D=21,80mm
24 A=37,80 B=5,70 C=3,30 D=28,80mm
25 A=40,80 B=5,70 C=3,30 D=31,80mm
26 A=45,30 B=5,70 C=3,30 D=36,30mm
A/B/C Total length & Dimensions
Contacts
Please select 1 option
001-050 Single row
004-100 Double row
006-120 Triple row
Plating
Please select 1 option
00 Au flash
10 Au 0,25µm
30 Au 0,75µm
50 Sn
Au flash min. 0,1µm
More plating options on request
Add to inquiry basket

B, C, D nach Kundenwunsch variierbar. Wir fertigen die Stiftleisten in jeder gewünschten Polzahl. Raster 5,08mm, 7,62mm, etc. oder Sonderraster sowie weitere Stiftlängen und Abmessungen auf Anfrage. Bestellseite "Sonderbestückungen bei Stiftleisten" unter Techn. Informationen.

B, C, D variable acc. to customers\' specifications. We will manufacture the pin headers in every desired number of contacts. 5.08mm, 7.62mm, etc. and varying pitches as well as more dimensions on request. Order page "Customer-specific Pin Configurations" in Technical Information.
