Technical Data
Shell Nickel plated brass
Insulator Thermoplastic, rated UL94 V-0
Contact Material Copper alloy
Contact Surface Gold over nickel (see options below)
Solder Side Plating Tin plated over nickel
Contact Resistance < 30 mΩ
Insulation Resistance > 1000 MΩ
Test Voltage 500 V AC
Voltage Rating 30 V RMS
Current Rating 1,5 A at 25°C
Temperature Range -55 °C ... +85 °C
Processing Wave Soldering
