Technical Data
Shell Nickel plated brass
Color Black
Insulator Thermoplastic, rated UL94 V-0
Contact Material Copper alloy
Contact Surface Gold over nickel (see options below)
Solder Side Plating Tin plated over nickel
RoHS Exemptions 6a-I / 6c none
Contact Resistance < 50 mΩ
Insulation Resistance > 100 MΩ
Test Voltage 300 V AC
Voltage Rating 30 V RMS
Current Rating 1 A
Temperature Range 0 °C ... +50 °C
Processing Reflow soldering 260 °C / 10 sec.
