Technical Data
Insulator Thermoplastic, rated UL94 V-0
Contact Material Copper alloy
Contact Surface Acc. to plating options, over Ni
Contact Resistance < 10 mΩ
Insulation Resistance > 10000 MΩ
Test Voltage 1390 V AC
Voltage Rating 180 V AC/DC Max.
Current Rating According to table below
Temperature Range -55 °C ... +125 °C
Processing Reflow soldering 260 °C / 10 sec. max.
