Technical Data
Insulator Thermoplastic, rated UL94 V-0
Contact Material Square pin 0.50mm, copper alloy
Contact Surface Au flash over Ni
Contact Resistance 20 mΩ max.
Insulation Resistance 500 MΩ min.
Test Voltage 500 V AC/DC
Current Rating 1 A
Temperature Range -40 °C ... +105 °C
Processing 230 °C for 30-60 seconds
(260 °C for 10 seconds)
(260 °C for 10 seconds)
